What are these holes for on this European travel adaptor?

What are these holes for on this European travel adaptor? - Mountainous valley with evergreen forest against misty sky

I have a standard European travel adaptor. What are the two circled holes on the top and bottom for?




Best Answer

Those circled holes will be for various plug style's grounds, however --

That is not a standard socket.

That is entirely an invention of the Chinese junk sellers.

It has not been approved by any competent testing laboratory, and it definitely never will. This type of socket is simply trying to adapt too many kinds of plugs, at the expense of safety, and it would not be able to be listed even if it was made by a competent builder. As such, the junk sellers don't even try to make a safe product. Hence the "for export only" sticker: export it to a jurisdiction we're not responsible for.

Use a listed adapter made for your specific plug-socket pair.

Note that UL, CSA, TUV, SGS, NTL, ETL etc. are marks of reputable testing agencies. CE is not a testing agency, nor is it reputable, as it allows manufacturers to self-test and self-certify, which turns the mark into “Chinese Excrement.” Relevant to electrical since so most of the world harmonizes to rules like US NEC, which require electrical equipment to be certified by a recognized testing lab. CE won't ever be one, for obvious reasons.

Hazards of cheapie multi-plug adapter by Big Clive

John Ward on these… And his teardown.




Pictures about "What are these holes for on this European travel adaptor?"

What are these holes for on this European travel adaptor? - Aerial Photo of A City
What are these holes for on this European travel adaptor? - Photo of Parc du Cinquantenaire
What are these holes for on this European travel adaptor? - Flat Bottom Boat On Water



Why do European plugs have 2 pins?

As previously mentioned above, due to the predominance of more powerful devices in the 1930s, (normally above around 500 watts), the problem of a possible electric shock became a hazard for users. In order to provide safety, an earth connection had to be fitted to 2-pole plugs for these devices.

How does a European plug work?

The Europlug is a flat, two-pole, round-pin domestic AC power plug, rated for voltages up to 250 V and currents up to 2.5 A. It is a compromise design intended to connect low-power Class II appliances safely to the many different forms of round-pin domestic power socket used across Europe.

How do you use a travel adapter?

The European system has one live leg carrying 230V with reference to ground, a neutral (the system ground), and a safety ground. Consequently, the European 230V system is wired similar to North American 125V house wiring.



TRAVEL ADAPTERS and Power PLUGS explained | World Travel Tips




More answers regarding what are these holes for on this European travel adaptor?

Answer 2

Your adapter is designed to acept a wide range of plug types, unfortunately this also tends to mean it accepts none of them well. The "for export only" label doesn't inspire confidence either. That basically means it is shoddy enough that even the country it was made in doesn't consider it safe.

The holes you have circled in red are to accept the earth/ground pins of the aforementioned wide variety of different plug types. Exactly what is hard to tell from the photo but I'm pretty sure at least UK, US and Australian plugs are supported by that hole combination.

Depending on just how crappy the adapter in question is you may or may not find it actually provides an earth connection between the Earth contacts on the Schuko style plug and the earth pin holes in the socket.

Answer 3

Various grounding pins.

Check Wikipedia on plugs and sockets, to see the variation.

I guess it makes a lot of sense to place the holes similar to what people are used to, and as far as I remember from that list (it's been a while since I spend hours reading through it), all plugs have the grounding pin placed symmetrically in relation to the live pins. And that has resulted in that layout.
