Is there a Macgyver-esque way to charge rechargeable batteries?
I am on a hiking trip an I forgot to pack the recharging device for my penlite batteries. I have enough power with me thanks to my solar panel. I can charge every device that is charging with usb. My garmin etrex vista however uses old fashion penlite (AA) batteries and I forgot to bring my AA charger. In the village where I am, the local shop doesn't sell AA batteries :(. I can use my gps, but only if it is connected to my solar panel, which doesn't make it practical when hiking through the mountains.
Since I do have energy with me in the form of a portable solar panel (10W), I am wondering if there is a Macgyver way to charge AA batteries.
Best Answer
Check whether your batteries are NiMh (or NiCd) or Lithium. Don't mix them, as they have different charging and discharging requirements. I assume you're not talking alkalines, and that you know you can't charge them :).
Use the 5 V output of the panel, anything higher will risk to blow up your batteries. As it's probably USB, it should be also limited (or it should be possible to limit) to 500 mA, which is actually still pretty high for Lithium batteries, and even more so for Nickel-based batteries.
Put at least 3 batteries in series (connecting the plus of one to the minus of another and so forth...). This will sum up their nominal voltage to about 4.5 V. For your safety, use only similar batteries (in capacity and chemistry) and possibly with the same charge level.
A resistance, as JoErNanO proposes, can be a good idea to limit the current. However, it won't prevent the batteries from overvoltage, and this can be quite dangerous so every once in a while check their charge level and if it's more than - say - 50-60%, stop charging them and use them. A better limiter for the voltage would be a diode, as it drops an approximately constant voltage. Try to also limit the current to less than 0.5 C, possibly less. 1C means that your battery fully charges in an hour (900 mAh -> 900mA).
You can also refer to the Nickel-metal-hydride guide, and Lithium guide at Battery University, they're quite complete and reliable. There is also a guide for charging from a USB port that should serve your purpose.
Pictures about "Is there a Macgyver-esque way to charge rechargeable batteries?"
What is the best way to charge rechargeable batteries?
Using a Battery Charger. Get an appropriate charger for the batteries you need to charge. Rechargeable batteries are most often charged in an A/C adapter, which you can plug into a basic home outlet. These chargers feature terminals sized in a variety of ways, from AAA to D.How can you recharge rechargeable batteries again?
Can I recharge any battery? You can only recharge a battery if it's specifically marked \u201crechargeable.\u201d Recharging a non-rechargeable battery may cause it to rupture or leak and may cause personal injury.How to use Rechargeable batteries: What you need to know
More answers regarding is there a Macgyver-esque way to charge rechargeable batteries?
Answer 2
Unfortunately you can't really charge batteries without a blocking diode which acts as a one way valve for the electricity. Judging by the fact that you didn't have access to AA batteries, you probably don't have a spare electronics parts store. Did you try asking for mignon or R6s (regional names for AAs)?
