Do I need to have an electrical converter when traveling to Sao Paulo/Brazil?

Do I need to have an electrical converter when traveling to Sao Paulo/Brazil? - Picturesque scenery of silhouette of Pico do Jaragua mountain with TV towers located in Sao Paulo against sunset sky

I am traveling from USA to São Paulo. Will it be possible to use cell phone charger, razor, etc without some sort of electrical converter and/or outlet adapter?



Best Answer

the outlets don't vary between regions in the country, but a new standard has been "invented" pissing everybody off because it's unique to Brazil, not seen in any other country...very clever!

So if you go to a newer property or if it's been recently renovated, you see a deep outlet that looks like this:

IEC 60906-1 (NBR 14136) plugs and outlet
Photo thanks to Wikipedia and Wikimedia Commons.

If you have this standard, there's no other choice but to buy a local adaptor.

If it's an old one, you'll have both the flat US plug and the round european style ones in the same outlet, which means you'll be able to use your appliances without a problem.

Sao Paulo has 110v.




Pictures about "Do I need to have an electrical converter when traveling to Sao Paulo/Brazil?"

Do I need to have an electrical converter when traveling to Sao Paulo/Brazil? - Architectural Photography of City
Do I need to have an electrical converter when traveling to Sao Paulo/Brazil? - Person Holding Smartphone
Do I need to have an electrical converter when traveling to Sao Paulo/Brazil? - Cityscape Against Cloudy Sky



What kind of plug adapter do I need for Brazil?

Use a Type N plug adapter for Brazil if your plug doesn't fit in a Brazilian power outlet.

Will US plugs work in Brazil?

While most European countries use 240 voltage, the US, Canada and much of South America continue to use 120 voltage, Brazil continues to support both types.

Does Brazil have same electrical outlet us?

Multiple readers have reported that Brazil uses mostly type "C" and 220V (hotels and big cities). Officially the plug type "N" is the definite and standard nowadays, it can be used with plugs type "C".

Will a European adapter work in Brazil?

Type C: Europe, Russia, AsiaType C adapters are also compatible with Type N adapters in Brazil\u2014but not anywhere else in South America.



TRAVEL ADAPTERS and Power PLUGS explained | World Travel Tips




More answers regarding do I need to have an electrical converter when traveling to Sao Paulo/Brazil?

Answer 2

Short answer: most likely you'll be able to use your devices in most places, but, just in case, bring a simple US-Europe power adapter like this:

US-Europe power adapter

Long answer: Brazil had always used both US and European power plug standards, but since 2011 ISO 60906-1 is the only acceptable one, i.e. now it's not allowed to sell the old plugs/sockets in stores. So you still see a lot of sockets from the older standard but new buildings use only the new one.

The only big issues with the new standard are the third (ground) pin, which is positioned differently than other common standards, and the plugs of devices rated higher than 20 A, which use a 4.8-mm pin diameter (and therefore don't fit in the normal socket). Devices like chargers and razors won't be affected if they use the adapter from the picture above.

Also keep in mind that the mains frequency is always 60 Hz, while the voltage can be either 127 V or 220 V, depending on the city and state. Be careful: in cities where the voltage is 127 V people sometimes take 2 phases from the mains to make one 220 V outlet, but in that case there's usually a very clear warning stuck on the wall.

Answer 3

Brazil has a new outlet standard which is the IEC 60906-1. You can easily buy the adapter in Brazil and you can still find some outlets like the ones in USA, specially at old places. The voltage at São Paulo is 127 V and the frequency is 60 Hz.

Answer 4

I've needed this adaptor in Sao Paulo, for:

  • Laptop power supply (works both with 110V/220V, schuko plug)
  • Hair dryer (220V/16A, schuko plug)

The outlets were 220V but the outlet pins were too thin for the schuko plug. You can find the adaptor around in "materiais de construção" shops.

enter image description here
